Error Code P2009
March-18th-2010, 05:47 AM
#2
Registered User
Join Date: Mar 2007
Location: Newark,ny
Posts: 913
P2009 = variable tumble solenoid circuit low
The solenoid is connected to battery power on one side, and the PCM on the other side... it pulls the PCM side to ground to energize the solenoid. When it turns off it monitors for the signal to go high again (since one side is battery and the PCM side should float high).
It turns on the error light when the signal stays low.
This means there's a burned out solenoid (no connection), bad battery connection at the solenoid, or a short in the wiring. Poor ground at the PCM (control module) can cause this as well.
The valve is in the vacuum system on the air intake manifold - located where the air intake attaches to the engine - front near the airbox. But from it's location i'd assume it could be a bad electrical connection from moisture hitting it (corrosion), or maybe got disconnected if the car went in for service.
No time to send a pic now, have to get to work. But if you're a do-it-yourself-er let me know and I can add a pic to the post.
Good luck
The solenoid is connected to battery power on one side, and the PCM on the other side... it pulls the PCM side to ground to energize the solenoid. When it turns off it monitors for the signal to go high again (since one side is battery and the PCM side should float high).
It turns on the error light when the signal stays low.
This means there's a burned out solenoid (no connection), bad battery connection at the solenoid, or a short in the wiring. Poor ground at the PCM (control module) can cause this as well.
The valve is in the vacuum system on the air intake manifold - located where the air intake attaches to the engine - front near the airbox. But from it's location i'd assume it could be a bad electrical connection from moisture hitting it (corrosion), or maybe got disconnected if the car went in for service.
No time to send a pic now, have to get to work. But if you're a do-it-yourself-er let me know and I can add a pic to the post.
Good luck
March-18th-2010, 01:16 PM
#3
Registered User
Thread Starter
Join Date: Mar 2010
Posts: 4
P2009 = variable tumble solenoid circuit low
The solenoid is connected to battery power on one side, and the PCM on the other side... it pulls the PCM side to ground to energize the solenoid. When it turns off it monitors for the signal to go high again (since one side is battery and the PCM side should float high).
It turns on the error light when the signal stays low.
This means there's a burned out solenoid (no connection), bad battery connection at the solenoid, or a short in the wiring. Poor ground at the PCM (control module) can cause this as well.
The valve is in the vacuum system on the air intake manifold - located where the air intake attaches to the engine - front near the airbox. But from it's location i'd assume it could be a bad electrical connection from moisture hitting it (corrosion), or maybe got disconnected if the car went in for service.
No time to send a pic now, have to get to work. But if you're a do-it-yourself-er let me know and I can add a pic to the post.
Good luck
The solenoid is connected to battery power on one side, and the PCM on the other side... it pulls the PCM side to ground to energize the solenoid. When it turns off it monitors for the signal to go high again (since one side is battery and the PCM side should float high).
It turns on the error light when the signal stays low.
This means there's a burned out solenoid (no connection), bad battery connection at the solenoid, or a short in the wiring. Poor ground at the PCM (control module) can cause this as well.
The valve is in the vacuum system on the air intake manifold - located where the air intake attaches to the engine - front near the airbox. But from it's location i'd assume it could be a bad electrical connection from moisture hitting it (corrosion), or maybe got disconnected if the car went in for service.
No time to send a pic now, have to get to work. But if you're a do-it-yourself-er let me know and I can add a pic to the post.
Good luck
March-20th-2010, 07:53 AM
#4
Registered User
Thread Starter
Join Date: Mar 2010
Posts: 4
March-22nd-2010, 08:52 AM
#6
Registered User
Thread Starter
Join Date: Mar 2010
Posts: 4
Also, where is the PCM?
Last edited by NashvilleKid; March-22nd-2010 at 09:00 AM.
September-11th-2012, 12:22 PM
#8
Registered User
Join Date: Sep 2012
Posts: 3
I just got this code last week. Wondering if this was fixed and if anyone else experienced this p2009 code as well.
My mazda3 sometimes doesn't start. Not even a sound, and most times everything is normal. Just odd. Engine light came on and this is the reading that came up. I do notice when it idles the engine idles up and down and gives off the feeling that it will shut off. But again this happens sometimes and not all the time.
My mazda3 sometimes doesn't start. Not even a sound, and most times everything is normal. Just odd. Engine light came on and this is the reading that came up. I do notice when it idles the engine idles up and down and gives off the feeling that it will shut off. But again this happens sometimes and not all the time.
November-9th-2012, 02:45 AM
#9
Registered User
Join Date: Nov 2012
Posts: 16
This pic is off a Mazda 3S 2.3L, I'm troubleshooting a TB issue with a P0507, pulled to check vacuum issues and received this code one disconnected.
P009 code is vacuum solenoid. Pic description, 18-740H/18-741C on top of page. One of these are bad.
Hope that helps.
~Mud
* left side box, picture rotated when uploaded?
P009 code is vacuum solenoid. Pic description, 18-740H/18-741C on top of page. One of these are bad.
Hope that helps.
~Mud
* left side box, picture rotated when uploaded?
Last edited by Mudnyrey; November-9th-2012 at 02:47 AM.
November-9th-2012, 04:04 PM
#11
Registered User
Join Date: Nov 2012
Posts: 16
November-9th-2012, 04:39 PM
#12
Registered User
Join Date: Sep 2012
Posts: 3
It was just a purge valve solenoid. It came with the hose. It was quite easy to replace actually. Cost was $130 CDN.
The error can also come from stripped wires so we searched out any wires that could have had
rubbed against metal.
The error can also come from stripped wires so we searched out any wires that could have had
rubbed against metal.
June-20th-2014, 07:19 PM
#13
Registered User
Join Date: Jun 2014
Posts: 5
code P2009
First post..
My daughters car is getting this code now so I'm about to replace solenoid. I can see that it has 2 vacuum lines and a electrical connector. My question is after that how is the darn thing mounted? looks to be a single nut with the mounting bracket? Yes I do have the maintenance manual but it doesn't show R&R of it. I read earlier post wanting to post pictures of the solenoid so here are a few I took. Hope it helps the next person. By the way her Mazda 3 stats are 2005, 175000 miles 2.0 liter.
My daughters car is getting this code now so I'm about to replace solenoid. I can see that it has 2 vacuum lines and a electrical connector. My question is after that how is the darn thing mounted? looks to be a single nut with the mounting bracket? Yes I do have the maintenance manual but it doesn't show R&R of it. I read earlier post wanting to post pictures of the solenoid so here are a few I took. Hope it helps the next person. By the way her Mazda 3 stats are 2005, 175000 miles 2.0 liter.
March-13th-2016, 04:37 PM
#15
Registered User
Join Date: Mar 2016
Posts: 2
